Original Fujikura CT-16 Optical Fiber Cleaver Cut Cutting Tools

FEATURES:

1. Applicable fiber: optical fiber type - single mode fiber/multimode fiber; fiber number - 2 single core fibers; cladding diameter - 125pm

2. Applicable coating: fiber tray AD-16A: one fiber with a maximum coating diameter of 900pm + one fiber with a maximum coating diameter of 250pm AD-16B: Max.3mm coating diameter; fiber fixture coating shape - refer to connector options

3. Cutting length: fiber tray AD-16A: 5~20mm*8 AD-16B * *C.D.: coating diameter C.D.=250pm or less: 5to20mm*8,250pm<C.D.<=900pm: 10to20mm 900pm<C.D.<=3mm: 14to20mm fiber fixture 10mm

4. Cutting angle*9: single mode fiber 0.3~0.9

5. Blade life*10: 48000 times
